High-durability equipment built in our own factory, designed for industrial livestock facilities.
Product Code: TAC-202
Material: The entire tank is manufactured from AISI 304 stainless steel.
Inner tank sheet thickness: 1.5 mm.
Outer wall sheet thickness: 1.0 mm.
The tank is equipped with a fully openable top lid.
Insulation: Made with 40 mm environmentally friendly polyurethane foam.
The tank cooling system is equipped with an evaporator (roll-bond) system.
Temperature measurement is provided by a high-precision digital thermometer.
The tank operates with a fully automatic system.
The control panel is designed to be simple and user-friendly.
At an ambient temperature of 32°C, it is equipped with a fan-cooled condenser capable of cooling from +35°C to +4°C in less than 3 hours.
Refrigerant gas: R404A.
Electrical system: 220V single-phase or optional 380V three-phase.
Phase protection relays are available against failures caused by voltage drops and surges.
Equipped with a 1 HP compressor.
The milk discharge valve is a DN40 chrome valve.
Equipped with a 40 Watt agitator/mixer.
Equipped with a transfer pump with a capacity of 6 tons per hour.
The weighing system is equipped with an electronic scale
View
View
View
View
Contact us for direct manufacturer pricing and custom sizes. Our engineering team replies within 24 hours.
